TO-92 Tape and Reel Data
TO-92 Packaging
Configuration: Figure 1.0
TAPE and REEL OPTION
FSCINT Label sample
See Fig 2.0 for various
FAIRCHILD SEMICONDUCTOR CORPORATION
HTB:B
Reeling Styles
LOT:
CBVK741B019
QTY: 10000
NSID:
PN2222N
SPEC:
FSCINT
D/C1:
D9842
SPEC REV:
B2
Label
QA REV:
5 Reels per
F63TNR Label sample
LOT: CBVK741B019
FSID: PN222N
(FSCINT)
QTY: 2000
SPEC:
Intermediate Box
F63TNR
Label
Customized
Label
D/C1: D9842
D/C2:
QTY1:
QTY2:
SPEC REV:
CPN:
N/F: F
(F63TNR)3
Customized
Label
375mm x 267mm x 375mm
Intermediate Box
TO-92 TNR/AMMO PACKING INFROMATION
AMMO PACK OPTION
Packing
Reel
Ammo
Style
A
E
M
P
Quantity
2,000
2,000
2,000
2,000
EOL code
D26Z
D27Z
D74Z
D75Z
See Fig 3.0 for 2 Ammo
Pack Options
Unit weight = 0.22 gm
Reel weight with components = 1.04 kg
Ammo weight with components = 1.02 kg
FSCINT
Label
Max quantity per intermediate box = 10,000 units
327mm x 158mm x 135mm
Immediate Box
5 Ammo boxes per
Intermediate Box
Customized
Label
(TO-92) BULK PACKING INFORMATION
Customized
Label
F63TNR
Label
BULK OPTION
333mm x 231mm x 183mm
Intermediate Box
EOL
CODE
J18Z
DESCRIPTION
TO-18 OPTION STD
LEADCLIP
DIMENSION
NO LEAD CLIP
QUANTITY
2.0 K / BOX
See Bulk Packing
Information table
Anti-static
J05Z
NO EOL
CODE
TO-5 OPTION STD
TO-92 STANDARD
STRAIGHT FOR: PKG 92,
NO LEAD CLIP
NO LEADCLIP
1.5 K / BOX
2.0 K / BOX
FSCINT Label
Bubble Sheets
94 (NON PROELECTRON
SERIES), 96
L34Z
TO-92 STANDARD
STRAIGHT FOR: PKG 94
(PROELECTRON SERIES
BCXXX, BFXXX, BSRXXX),
97, 98
NO LEADCLIP
2.0 K / BOX
2000 units per
EO70 box for
std option
114mm x 102mm x 51mm
Immediate Box
5 EO70 boxes per
intermediate Box
530mm x 130mm x 83mm
Intermediate box
C ustomized
Label
FSCINT Label
10,000 units maximum
per intermediate box
for std option
?2001 Fairchild Semiconductor Corporation
March 2001, Rev. B1
